Chapter 8
8 - 2
8400 specifications
The following specifications apply to only the 8400 IP Application Switch
platform.
Only optics modules provided by F5 Networks are supported in this
platform.
Specifications are subject to change without notification.
Item Specification
Dimensions 3.5"H x 19"W x 24"D (per unit) 2U industry standard
rack-mount chassis
Weight 43 lbs. (single power), 46 lbs. (dual power) per unit
Processor Dual Opteron 2.6 GHz
Power Supply Optional redundant power supply
ASIC Packet Velocity ASICâ„¢ 10 (PVA 10)
Network Interfaces 12x10/100/1000 Copper ports
12x1000Base-X SFP Fiber ports
1000BASE-SX - 850nm (LC Connector, 6 modules
included)
1000BASE-LX - 1310nm (LC Connector, optional)
2x10 Gigabit XFP ports
10GBASE-SR - 850nm (LC Connector, optional)
1x10/100 Ethernet Management port
Hard Drive Capacity 512 MB flash with 80 Gigabyte hard drive
RAM 2 GB (expandable to 4 GB)
Power supply type 460W 90/240 +/- 10% VAC AUTO Switching
Input Voltage and
Current
90-132 9A
80-264 4A
Typical power
consumption
460W (AC)
Heat generated 1365 BTU/hour
Table 8.2 The 8400 IP Application Switch platform specification
