402 Installation
OPEN/HOLD OPEN DEVICE: To open hold the gate
open, you must use a latching switch wired to terminals
18 and 19.
STOP BUTTON: The stop button you install must have
normally closed (N.C.) contacts. Multiple stop buttons
must be wired in series. Connect your stop device
between terminals 14 and 15.
THE LED INDICATORS: The five light-emitting diodes
(LEDs) on the control panel can be used to check for the
proper functioning of the devices you attach to the
control panel. The LED lights are on whenever the
contacts are closed across each of the respective
terminals.
DL1 and DL2 should illuminate only when an activating
signal is sent for 2 and 1 gate leaves, respectively. DL3
should be illuminated except when the stop button is
pressed. DL4 and DL5 should be illuminated except
when the reversing devices, for opening and closing,
respectively, are triggered. Use the LEDs and the next
table to determine if the accessory devices you have
installed are operating properly.
ELECTRIC LOCK: Connect your lock to the terminals 24
and 25. The terminals provide 12 VAC that pulses for 4
seconds whenever the gate starts to open. An electric
lock can make use of the reversing stroke function
controlled by DIP switch 5. A reversing stroke is a short
closing phase that allows the electric lock time to
disengage itself before the operator starts its opening.
Turn DIP switch 5 on only if necessary for your lock to
function correctly.
See Figure 11 for the wiring of a magnetic locking
device.
the general control panel layout, and refer to Figure 9
for the layout of the terminal strip.
POWER SUPPLY FOR ACCESSORIES: You can access a
30 VDC output for supplying power to accessories that
require DC voltage through terminals 9 and 10 (located
above the label 30 Vcc) on terminal block J3. In most
cases, this source can be used to power 24 VDC
accessories.
N
OTE: The 450 MPS control panel allows a
maximum accessory load of 800 mA.
REVERSING DEVICES: Reversing devices include
photobeams, inductive loops, and so forth. All of the
reversing devices should have contacts of the normally
closed (N.C.) type. Where you connect a device depends
on whether you want the device to operate during
opening or during closing.
Note: UL does not recognize the FAAC system
with loop detectors or safety edges. FAAC
photobeams must be used to comply with UL 325.
Caution: Failure of a reversing device that
operates during opening causes a gate to lock
in the closed position and requires the use of
the Manual Release.
To wire photobeams, refer to Figure 9 (see FSWOP for
opening photobeams, and FSWCL for closing
photobeams— wire the photobeams exactly as shown).
See Figure 11 for the wiring of a variety of common
accessories. In either case, if you have multiple devices,
wire them in series.
ACTIVATING DEVICE: The activating device for your
gate must have normally open (N.O.) contacts. If you
have a dual gate, connect devices to terminals 18 and
19. If you have a dual gate and want a particular device
to open only one leaf, connect it to terminals 16 and
17.
DECODER CARD: If you are installing a FAAC radio
receiver, a Digicard magnetic card reader, or a Digikey
keypad, use the quick-fit connector J4 for the radio
receiver or the DS (formerly the MD01) decoder card
(see Figure 8).
N
OTE: If you are using both a receiver and a
decoder, hard wire the decoder and plug the
receiver in.
LED On Off
DL1,
Open 2 leaves
Command active Command inactive
DL2,
Open 1 leaf
Command active Command inactive
DL3, Stop Command not
active
Command active
DL4,
FTSW Open
Opening reversing
devices not
triggered
Reversing device
triggered
DL5,
FTSW Close
Closing reversing
devices not
triggered
Reversing device
triggered
