Page 8
August, 2002
402 Installation
E (Semi-automatic) Logic (450 MPS)
Gate Status Open A Open B Stop Opening
Reversing
Device(s)
Closing
Reversing
Device(s)
Warning
Light
Closed Opens both leaves
Opens single leaf
connected to
Motor 1
No effect No effect No effect Off
Opening Stops Stops Stops
Stops; gate closes
when reversing
device no longer
triggered
No effect On
Opened
Closes both leaves
immediately
Closes leaf
immediately
Stops No effect
No effect
(opening is
inhibited)
On
Closings Stops Stops Stops
No effect
(opening is inhibited)
Depends on DIP
switch 4
Flashes
Stopped Closes the leaves Closes the leaf
No effect
(opening is
inhibited)
No effect
No effect
opening is
inhibited)
On
Gate Status Open A Open B Stop Opening
Reversing
Device(s)
Closing
Reversing
Device(s)
Warning
Light
Closed Opens both leaves Opens single leaf
connected to
Motor 1
No effect
(opening is
inhibited)
No effect
(opening is inhibited)
No effect (opening
is inhibited)
Off
Opening Stops Stops Stops Stops; gate closes
when reversing
device no longer
triggered
No effect On
Opened Closes both leaves
immediately
Closes leaf
immediately
Stops No effect No effect (opening
is inhibited)
On
Closing Stops Stops Stops No effect
(opening is inhibited)
Depends on DIP
switch 4
Flashes
Stopped Gate leaves reverse
direction
Gate leaf reverses
direction
No effect
(opening is
inhibited)
No effect
(opening is inhibited)
No effect
(opening is
inhibited)
On
EP (Semi-automatic, Step by Step) Logic (450 MPS)
Gate Status Open A Open B Stop Opening
Reversing
Device(s)
Closing
Reversing
Devices(s)
Warning
Light
Closed Opens 1 or
both leaves
No effect No effect No effect No effect Off
Opening No effect No effect Stops No effect Stops On
Opened No effect Closes 1 or
both leaves
No effect No effect No effect On
Closing No effect No effect Stops Stops No effect Flashes
Stopped Opens 1 or
both leaves
Closes 1 or
both leaves
No effect No effect No effect On
