FAAC S418 Instruction Manual

2
FAAC Model S418 Swing Gate Operator
CONTENTS
FAAC Model S418 - Rev: 01.0C.05 - APR 2011
Read this instruction manual before you begin installing the product.
= Information regarding personal safety and proper maintanence of the product.
IMPORTANT SAFETY INFORMATION 3
Important Safety Instructions 3
Important Installation Instructions 3
General Safety Precautions 4
UL325 Gate Operator Classications 5
Installing the Warning Signs 5
1. DESCRIPTION 6
1.1 DIMENSIONS 6
2. TECHNICAL SPECIFICATIONS 7
3. INSTALLATION 7
3.1 ELECTRICAL PREPARATIONS SETUP 7
3.2 PRELIMINARY CHECKS 7
3.3 INSTALLATION DIMENSIONS 8
3.4 INSTALLING THE OPERATOR 9
3.5 WIRING THE OPERATOR 12
3.6 MECHANICAL STOPS 12
4. AUTOMATED SYSTEM TEST 13
5. MANUAL OPERATION 13
5.1 RESTORING NORMAL OPERATION 13
6. SPECIAL APPLICATIONS 14
7. MAINTENANCE 14
8. REPAIRS 14
9. ACCESSORIES 14
10. S418 PARTS DIAGRAM 15
LIMITED WARRANTY 16

FAAC S418 Specifications

General

Power Supply	230V AC (+6% -10%) 50Hz
Motor Voltage	24V DC
Operating Temperature	-20°C to +55°C
Protection Class	IP54
Limit Switch Type	Magnetic
Control Voltage	24V DC
Frequency of Use	Intensive use
