Fagor HCG-10/21 - Frequency Inverter (T-083002); VR 4605-VA 1041 B Valve (Convection Gas Valve)

22
VR 4605-VA 1041B Valve (Convection Gas Valve)
fig 24
Frequency inverter (T-083002)
fig 25
fig 26
P.outlet
P.inlet
Ignition speed
switches
Max
imum operating
speed switches
Detailed view of frequency
inverter switches
Air/gas regulation in ignition.
(maximum speed)
Air/gas regulation in ignition.
(Offset )
((+) clockwise)
