/ INSTALLING YOUR APPLIANCE
••
CHOOSING THE POSITION
The distance between the edge of your appliance
and the side and rear walls (or partitions) must be
at least four centimetres (zone A).
YYoouurr aapppplliiaannccee mmaayy bbee bbuuiilltt iinn wwiitthhoouutt aannyy rreessttrriicc--
ttiioonn.. CChheecckk,, hhoowweevveerr,, tthhaatt tthhee aaiirr iinnttaakkee aanndd
oouutt--
lleett aarree ffrreeee ooff oobbssttrruuccttiioonn ((sseeee ““ddeessccrriippttiioonn ooff
yyoouurr aapppplliiaannccee”” cchhaapptteerr))..
The building-in method opposite is recommended
for use above an oven or a built-in appliance.
BUILDING-IN
Follow the diagram above.
Glue the foam seal underneath your appliance, fol-
lowing the perimeter of the hole in the worktop,
upon which your appliance will rest. This will
ensure a good seal against the worktop.
Attach the clips to the hob
(depending on the
model
).
vveennttiillaattiioonn ssppaaccee
5511
••
5588
4499
5566
66,,44
AAbboovvee aann oovveenn
MIN 4 mm
AAbboovvee aa ccaabbiinneett
wwiitthh aa ddoooorr oorr ddrraawweerr
Tip
If your hob is located above your oven, the hob’s thermal safety devices can impede the
simultaneous use of the hob and the oven’s pyrolysis program.
Your hob is equipped with an anti-overheating safety system.
This safety device can trigger, for example, when the hob is installed over an oven that is not suf-
ficiently insulated. If this occurs, a series of small lines appears on the control panel. In such cir-
cumstances we recommend that you increase the hob’s ventilation by creating an opening in the
side of the cabinet, (8 x 5 cm), and/or installing an oven insulation kit available from the after-sales
department.
Air outlet
Air intake
