13. Technical Data
This cooker is designed for use on Natural Gas, although a conversion for LP (LPG X Propane (2.54 kPa)) gas is packed with the
cooker.
INSTALLER: Please leave these instructions with the user.
DATA BADGE LOCATION: Cooker back, serial number repeater badge below oven door opening.
Country of destination: Australia.
Connections
Gas (Rp ½ at rear right-hand side) Electric
Natural gas
1 kPa
230 V 50 Hz
Propane
2.54 kPa
See the appliance badge for test pressures.
Dimensions Refer to ‘Positioning the Cooker’.
Overall height
minimum 905 mm maximum 930 mm
Overall width
1092 mm
Overall depth
608 mm excluding handles; 670 mm including handles
Minimum space above the hotplate
650 mm
Ratings
Hotplate Bypass Screw*
Natural Gas 1 kPa LP Gas 2.54 kPa
Input Injector Input Injector
Wok burner
55 15.2 MJh¯1
Internal 88
15.0 MJh¯1
Internal 57
External 168 External 98
Large burner
41 12.3 MJh¯1 165 12.0 MJh¯1 89
Medium burner
33 6.2 MJh¯1 115 6.2 MJh¯1 67
Small burner
25 3.7 MJh¯1 92 3.3 MJh¯1 48
* The valves in this cooker are tted with adjustable bypass screws. The cooker is supplied with the bypass screws set for Natural gas. For LPG conversion the
bypass screws must be screwed all the way down.
Oven Efficiency
Ovens
Left-hand Oven Right-hand Oven
Forced Air Convection Forced Air Convection
Maximum power output @ 230 V 50 Hz
2.5 kW 2.5 kW
Energy eciency class on a scale of A (more ecient) to G (less ecient)
A A
Energy consumption based on standard load
0.90 kWh 0.90 kWh
Usable volume (litres)
79 79
Size
Large Large
Time to cook standard load
38 minutes 38 minutes
Surface area of the grid
1400 cm2 1400 cm2
Grill
2.3 kW
Warmer
160 W
Maximum total electrical load at 230 V (approximate total including oven lights, oven fan, etc.): 7.43 kW.
