Falcon D261M User Manual

25
50
37
9
7
53
52
13
52
12
43
For F (UL)
17
D100/200 Series Service Manual
Assemblies
Call Out
Number Description Part Number
Call Out
Number Description Part Number
7 Mounting Plate B600-018 37 Driver Bar B600-041
9 Mounting Plate, Blank B600-098 43 Fire Cup (F only) *
12 Fire-Rated Bolt (F only) * 50 Screw, Mounting (2) B520-662
13 Regular Bolt Q330-253 52 Screw, Deadbolt (2) C603-897
25 Thumbturn Assy B302-041 53 Screw, Trim (2) B600-066
D261M
Thumbturn, Inside x Rose
* Not for sale as individual parts.

Falcon D261M Specifications

General

Brand	Falcon
Model	D261M
Category	Door locks
Language	English
