D100/200 Series Service Manual
FALCON ANSI
D111 E0171
D151
Classroom
Function
Single Cylinder
x Rose
Double Cylinder*
Single Cylinder
x Thumbturn
Thumbturn
x Thumbturn
Inside turn will only retract
bolt. Bolt automatically
deadlocks when fully
thrown.
Blank plate inside. Bolt
automatically deadlocks
when fully thrown
Deadbolt thrown or
retracted by key from either
side. Bolt automatically
deadlocks when fully
thrown.
Deadbolt thrown or
retracted by turn. Bolt
automatically deadlocks
when fully thrown.
Deadbolt thrown or
retracted by turn.
* Caution: Double cylinder locks on residences—or on any door in any structure which is used for egress—are a life safety
hazard in times of emergency, and their use is not recommended. Installation should be in accordance with existing codes only.
Lock Assembly Drawing Index
Function
BHMA/ANSI A156.6, 2001, Grade 1
CYLINDERS
OUTSIDE FUNCTION INSIDE FUNCTION
Deadbolt thrown or
retracted by key from
outside.
Deadbolt thrown or
retracted by key from
outside.
Deadbolt thrown or
retracted by key only.
Deadbolt thrown or
retracted by key from
either side.
Deadbolt thrown or
retracted by turn.
Lock Assembly Drawing Index
Standard cylinder.
SFIC - small format
interchangeable core option.
D121 E0161
D131 E2141
D141 E2151
P.4
P.4
P.5
P.5
P.7
P.6
P.8
P.8
P.9
PAGE
FUNCTION
