28
SSG2.2KRM / SSG3KRM Models
UPS shown for illustration purposes only, rear panel layout and operating voltage may vary.
1. Place the battery circuit breaker in the ON (up) position.
2. Connect the supplied AC power cord to the UPS input plug inlet. (-2 Models)
a. Connect the AC power cord plug to a properly rated wall receptacle. (-1 Models)
3. Turn on the AC power switch located on the front panel.
4. Allow 30 to 45 seconds for the UPS to complete power on self-test.
5. Confirm the UPS display icons for online mode operation. See below.
6. Connect the load to the output receptacles then power on the load.
Battery Cable
Battery Circuit Breaker
To Next Page
