To get started with using the CSL Pedals Load Cell Kit, decide on your
preferred pedal module position, and pedal plate position. then connect the
CSL Pedals Load Cell Kit to your wheel base via the included RJ12 cable
or to a PC via USB. It is important to follow the chapter sequence of this
manual for an eective assembly and setup procedure.
ATTENTION: See chapter 4.4 “Connections” for which pedal module must
be connected to which port of the CSL Pedals Load Cell module. Only
use the included USB and RJ12 cable from your CSL Pedals Load Cell Kit
package contents to avoid damages!
ASSEMBLY
PLAN YOUR SETUP
4
4.1
ATTENTION: Place the CSL Pedals Load Cell Kit box on its side in order to
remove the contents without dropping any items and to avoid damages!
