Step 11
Page 12fantasticfurniture.com.au
You will need
Insert 1 x dowel (H16) into each drawer side panel (P7, P8) as shown.
Use a mallet to gently tap the dowels into place if needed.
Step 12
H16
You will need
X
2
Mallet
4 x Dowels
ø6mm (H16)
H16
(P7)
(P8)
Position 1 x drawer left side (P7)
and 1 x drawer right side (P8)
and 1 x drawer support (P11) onto
drawer front (P6) ensuring the grooves
in each panel align.
Insert 6 x small cam nuts (H15)
into drawer sides (P7, P8) and drawer support (P11).
Rotate the cam nuts so the arrows point towards
the incoming cam bolts. Using a flat head screwdriver turn clockwise to lock.
Repeat this step for the other 1 x drawer left side (P7), 1 x drawer right side (P8)
and 1 x drawer support (P11).
X
2
(P8)
(P7)
(P11)
H15
H15
H15
(P6)
H1
H1
H1
H1
H1
Screw 6 x cam bolts (H1) into each drawer front (P6), using a phillips head screwdriver.
12 x Cam Bolts
(H1)
Phillips Head
Screwdriver
X
2
Step 13
You will need
Flat Head
Screwdriver
12 x Small Cam
Nuts (H15)
(P6)
To Next Page
