Step 5
Page 8fantasticfurniture.com.au
You will need
Phillips Head
Screwdriver
6 x Screws
12mm (H18)
4 x Slides
(H19)
Mallet
H19
Separate the slide runners (H19-2) and slide tracks (H19-1)
from 4 x slides (H19) by following the steps below:
Extend the slide runner all the way out.
Press down the plastic release lever on the slide
and pull out the slide runner (H19-2) completely.
H19
Slide runner H19-2
Slide track H19-1
Note the position
of the rubber stopper
Attach 1 x separated slide track (H19-1) onto side panels (P3) with 3 x screws (H18),
using a phillips head screwdriver as shown.
Repeat this step for the other side panel (P3).
Ensure the slide tracks (H19-1) are attached so the rubber stopper is positioned near
the grooves on the side panel (P3).
Insert 4 x dowels (H3) into each panel (P3) as shown.
If needed use a mallet to gently tap the dowels into place.
H19-1
8 x Dowels
ø8mm (H3)
H18
(P3)
H3
H3
H3
H3
X
2
H18
H18
H19-1
H19-1
H19-1
Adjust runner to access the screw holes.
Please fasten the screws through
these holes for this step.
To Next Page
