Fantec XMP600 - Front Panel; Rear Panel; Side Panel

ENGLISH
15 / 54
2.2 Front Panel
1. Power indicator
3. Eject button
5. Memory card slot
7. Function key
(PLAY-PAUSE/ PREV/ STOP/ NEXT)
2. DVD ROM tray
4. Display
6. USB Host port (A-Type)
2.3 Rear Panel
1. Y/Pb/Pr OUT jack 2. A/V OUT jack
3. HDMI jack 4. RJ45 LAN socket
5. S/PDIF COAXIAL jack 6. S/PDIF OPTICAL jack
7. USB HOST port (A-Type) x 2 8. USB DEVICE port (B-Type)
9. Scart out 10. DC IN jack
11. Power Switch
2.4 Side Panel
1. HDD mobile rack
