13400 Owner’s Manual
P/N 446613 Issue I Rev. A V-3
Faraday
Detector
w/Base
Mfg. Detector
w/Base
Number of
Detectors Per
Circuit
Maximum
Standby
Current
Detector
Identifier
Base
Identifier
System Sensor (Cont’d)
9419 2100 0-30 0.100mA A ---
9420 2100T 0-30 0.100mA A ---
9358 w/9361 1451 w/B401B 0-25 0.120mA A A
9358 w/9364 1451 w/B401 0-25 0.120mA A A
9358 w/9424 1451 w/B406B 0-25 0.120mA A A
9359 w/9361 2451 w/B401B 0-25 0.120mA A A
9359 w/9364 2451 w/B401 0-25 0.120mA A A
9359 w/9424 2451 w/B406B 0-25 0.120mA A A
9360 w/9361 2451TH w/B401B 0-25 0.120mA A A
9360 w/9364 2451TH w/B401 0-25 0.120mA A A
9360 w/9424 2451TH w/B406B 0-25 0.120mA A A
9447 w/9361 5451 w/B401B 0-25 0.120mA A A
9447 w/9364 5451 w/B401 0-25 0.120mA A A
9447 w/9424 5451 w/B406B 0-25 0.120mA A A
9421 w/9361 4451HT w/B401B 0-25 0.120mA A A
9421 w/9364 4451HT w/B401 0-25 0.120mA A A
9421 w/9424 4451HT w/B406B 0-25 0.120mA A A
9176 DH400I (1451DH w/DH400) 0-25 0.120mA A A
9177 DH400P (2451 w/DH400 0-25 0.120mA A A
Faraday
8854 w/8853 8854 w/8853 0-27 0.110mA 8854 8853
8842 w/8853 8842 w/8853 0-27 0.110mA 8842 8853
8843 w/8853 8843 w/8853 0-27 0.110mA 8843 8853
8854 w/8840 8854 w/8840 0-27 0.110mA 8854 8840
8854 w/8853 &
8845 or 8849
8854 w/8853
& 8845 or 8849
0-27 0.110mA 8854 8853
8842 w/8853 &
8845 or 8849
8842 w/8853
& 8845 or 8849
0-27 0.110mA 8842 8853
8843 w/8853 &
8845 or 8849
8843 w/8853
& 8845 or 8849
0-27 0.110mA 8843 8853
8854 w/8840 &
8845 or 8849
8854 w/8840
& 8845 or 8849
0-27 0.110mA 8854 8840
8854 w/8853 &
8844 or 8848
8854 w/8853
& 8844 or 8848
0-13 0.220mA 8854 8853
8842 w/8853 &
8844 or 8848
8842 w/8853
& 8844 or 8848
0-13 0.220mA 8842 8853
8843 w/8853 &
8844 or 8848
8843 w/8853
& 8844 or 8848
0-13 0.220mA 8843 8853
8854 w/8840 &
8844 or 8848
8854 w/8840
& 8844 or 8848
0-13 0.220mA 8854 8840
Notes:
1. These detector models may be mixed and matched as long as the total maximum standby
current does not exceed 3.0 mA per initiating device circuit. The total number of detectors on
a circuit should not exceed 30.
2. This control unit is not intended to handle more than one 2-wire detector in alarm, per circuit.
3. The activation of a manual pull station or any other contact device, will prevent any 2-wire
detector on the same circuit from remaining activated or from activating.
4. If the smoke detector has an alarm verify function, the circuit must not be programmed for
alarm verify,
5. For specific wiring and installation information, read the instructions provided with each
device.
