1. TECHNICAL CARACTERISTICS
FUNCTIONS: Arranger On/Off, Split 19/24, Ground On/Off,
Chord Memory On/Off, Medley Song On/Off, MIDI IN On/
Off, Portamento, 5 Touch levels, Midi Melody On/Off chan-
nel 4, Info TV On/Off, Delete file, Setting colours on TV
General control: ON/OFF, Master Volume, Microphone
volume, Select, Easy Play, Style, Song, Sund, USB, Dual,
Touch, Section volumes, Split/Full keyb., Play/Pause, Up,
Down, Back, Bending, Modulation
DEMO: Demonstrative song
SONGS: 100 pre-recorded musical songs with Medley
Song On/Off
MAESTRO: 5 learning levels (LESSONS)
DICTIONARY: Chord glossary on display
PROGRAMS: 40 programs for setting keyboard, 10 of
which are programmable
AMPLIFICATION: 5 + 5 watt stereo (RMS) - Two high-effi-
ciency Ø 100 mm loud speakers
POWER SUPPLY
: 8 x 1.5 Volt IEC R14/C batteries
AC/DC adapter: Vdc= 12 V / I = 2.25
VIDEO OUT: Socket for connecting a TV – PAL system,
COMPOSITE VIDEO output signal
LINE AUDIO OUT L / R: RCA sockets for external audio
connections
USB TO DEVICE: Socket for connecting a USB FLASH DRIVE
USB TO HOST: Connection to a computer for data recep-
tion and transmission
PEDAL SWITCH: Socket for sustain pedal
INPUT DC 12V: Socket for connecting mains adapter
PHONES/AUX-OUT: Socket for headphones and external
amplification
MIKE: Socket to connect microphone
LEVEL: Volume regulation of microphone
DIMENSIONS: (945 x 360 x 125) mm
WEIGHT: 6 Kg
KEYBOARD: 61 professional keys (C-C) touch sensitive
(DYNAMICS)
TOUCH: immediate exclusion and restoration of sensitivity to
touch (DYNAMICS)
POLYPHONY: maximum 64 notes
DISPLAY: 80 x 40 mm LCD - backlit
4 luminous CONDUCTORS
BASIC SOUNDS: 216 polyphonic tones
MIXED SOUNDS: thousands of combinations of sounds
EQUALISER: 4 equalization levels
TRANSPOSER: range +/– 12 semitones
PIANO: immediate selection of the piano tone
SYNTH SECTION: 16 SYNTH sounds editable with Personal
Computer
SOUNDS FOR ACCOMPANIMENT: 216 polyphonic tones
EFFETTI: 8 CHORUSES, 8 REVERBS and SUSTAIN
ECHO: effect for microphone input
STYLES: 125 rhythms with 4 ORIENTAL, 8 PIANIST, 25
SONG STYLES
Controls: START/STOP, DOWN BEAT, TEMPO +/–, KEY
START/FILL IN, BREAK, INTRO, ENDING, FADE
METRONOME: with immediate control
MANUAL DRUM: 8 rhythm percussion groups on keyboard.
SEQUENCER: REC and PLAY to record and listen.
SAVE to save on USB FLASH DRIVE (not included)
MIDI FILE MEMORY: to load and reproduce midi file
backing tracks from USB FLASH DRIVES
KARAOKE SCREEN INTERFACE: to view the texts of the
songs, folders and files of the USB FLASH DRIVE on a TV
SCREEN (not included) – reads the main LYRIC / KAR for-
mats
AUTOMATIC ACCOMPANIMENT: Free Chord, Easy Chord,
Arranger A and B, LARGE
2. INTRODUCTION
The package contains:
Adaptor
ADS 1223
User's manual
Music book
Music standMicrophone
Number strip
Keyboard TK 89
USB connecting cable
to a PC
VIDEO cable for
connection to TV
