Assembly - Teleswing
29
Part Identification
ITEM PART NUMBER DESCRIPTION QTY.
1 811414 ELBOW 90 3/4 MORB X 3/4 MJIC 1
2 811416 ELBOW -10 MORB X -8 MJIC, 90 DEG 1
3 811469 ADAPTOR STRAIGHT -8 MNPT X -8 MNPT 2
4 811916 ELBOW -8MORB X -6MJIC 90DEG 4
5 812026 HEX BOLT 5/16" X 1" (PL) 2
6 812084 ADAPTER -6MJIC X -6MPT 2
7 812107 ADAPTOR STR 3/4MORB X 9/16MJI 2
8 812208 NIPPLE 1/2 BODY 1/2 -14 NPTF QUICK CONNECT 2
9 812320 ADAPTER -8 MPT X -6 MJIC 2
10 812362 LOCK NUT 5/16" (PL) 2
11 81925 HEX BOLT 5/16" X 1 3/4" (PL) 1
12 886897 ADAPTOR STR 7/8MORB X 3/4MJIC S 2
13 913969 ELBOW-6 MPT X -6 FPT 90 1
14 914276 VALVE-CHECK -8 MPT X -8 FPT 1
15 914818 BRKT - HYD HOSE CLAMP 2
16 919398 ELBOW -6 FJIC X - 6 MJIC, 90° 2
17 932238 HOSE -6 X -6 JIC X -6JIC, L = 54” 2
18 932239 HOSE -4 X -6JIC X -6JIC, L = 73” 2
19 932240 HOSE -6 X -6JIC X -8JIC, L = 201” 2
20 932241 HOSE -6 X -8NPT X -8JIC, L = 356” 2
21 932318 BRKT - HYD HOSE CLAMP 1
22 966307 ADAPTOR 1/2MNPT X 1/2FNPT - .0520R 1
