SERVICE SCHEDULE
Maintenance Intervals
Maintenance work must be done at regular intervals. Failure to do so will result in excessive wear and
early failures. The service schedule is a guide for correct maintenance of the equipment.
WARNING
Instructions are necessary before operating or servicing equipment. Read and understand the
Operator and Parts Manual and safety signs (decals) on equipment. Follow warnings and instructions
in the manuals when making repairs, adjustments or servicing. Check for correct function after
adjustments, repairs or service. Untrained operators and failure to follow instructions can cause
injury or death.
Item DESCRIPTION
SERVICE PROCEDURES
Check Clean Lube Change Cover
Daily Maintenance (or every 8 hours)
1 Bushing - Hopper Feed Screw
•
2 Bushing - Hopper Jack Shaft
•
3 Bushing - Transition Screw
•
Every 80 Hours
4 U-Joint - Lower Hopper
•
5 U-Joint - Upper Hopper
•
6 U-Joint - Collector
•
7 Hopper Chain Drive
• •
8 Spline Shaft
• • •
9 Chain Box Chain Drive
• •
Every 200 Hours
10 Bearings - Hopper Feed Screw
•
11 Bearings - Jack Shaft
•
12 Bearings - Chain Box
•
13 Gearbox - Collector (Oil SAE 90)
• •
To Next Page
