Parts Identiļ¬cation - Teleswing
53
ITEM PART NUMBER DESCRIPTION QTY.
1 812026 5/16" X 1" HEX BOLT (PL) 2
2 812362 5/16" LOCK NUT (PL) 11
3 812363 3/8" LOCK NUT (PL) 12
4 812365 3/4" LOCK NUT (PL) 2
5 812482 5/8" LOCK NUT (PL) 6
6 812624 1/4" FLAT WASHER PL 8
7 812639 WASHER 0.625 SAE FLAT BS PL 6
8 81527 1/4" X 1" HEX BOLT (PL) 4
9 81546 5/16" FLAT WASHER (PL) 8
10 81553 5/16" X 1 1/2" HEX BOLT (PL) 6
11 81558 5/16" X 2 3/4" HEX BOLT GR5 (PL) 3
12 81578 3/8" X 1 3/4" HEX BOLT (PL) 8
13 81681 3/4" X 1 1/2" HEX BOLT (PL) 2
14 84039 WASHER - 3/8" SAE FLAT (PL) 12
15 84050 3/4" S.A.E. FLAT WASHER (PL) 4
16 84498 1/4" LOCK NUT (PL) 16
17 914429 CLAMP HOSE-2.06 TO 21.25 2
18 931392 PLATE - COLLECTOR COVER WEAR STRIP 4
19 931528 WEAR BUTTON 8
20 931529L PLATE - SWIVEL SPACER BLOCK 4
21 931530 HOOD CATCH KIT 2
22 931640 1/4" X 1" FLAT SOCKET CAP SCREW GR.5 (PL) 12
23 931725 ASSY - WHEEL DRIVE 1
24 932080 Q45 3 SPOOL HYDRAULIC VALVE 1
25 932117 10-24 X 3/4 PAN HEAD MACH. SCREW GR.5 (PL) 4
26 932118 #10-24 LOCK NUT (PL) 4
27 932242 HOPPER SWIVEL BUSHING 2
28 932295 ENERGY CHAIN 12 FT
29 932306 ENERGY CHAIN MOUNTING BRACKET 1
30 932410 ENERGY CHAIN MOUNTING BRACKET 1
31 932667 CYLINDER, 2.5" BORE X 4" STROKE 1
32 932668L PLATE - FLANGE HOLDER 4
33 932673 ASSY - 16" TELESWING HOPPER 1
34 932764 BRKT - INNER BOLT BRACE RIGHT 1
35 932765 BRKT - INNER BOLT BRACE LEFT 1
36 932771 WELDT - TRANSITION LID 1
37 932772 WELDT - RETRACTOR BOX 1
38 932931 COVER-INPUT BOX PIVOT 1
39 932939 WELDT - COLLECTOR COVER 1
40 932941 ASSY - COLLECTOR 1
41 933073 ASSY - INTAKE TUBE 1
