Parts Identiļ¬cation - Teleswing
57
ITEM PART NUMBER DESCRIPTION QTY.
1 811796 1/2" X 2 1/2" HEX BOLT GR5 (PL) 1
2 812026 5/16" X 1" HEX BOLT (PL) 10
3 812362 5/16" LOCK NUT (PL) 10
4 812363 3/8" LOCK NUT (PL) 20
5 812364 1/2" LOCK NUT (PL) 3
6 812482 5/8" LOCK NUT (PL) 1
7 812639 WASHER 0.625 SAE FLAT BS PL 2
8 81544 1/4" HEX NUT (PL) 1
9 81546 5/16" FLAT WASHER (PL) 26
10 81553 5/16" X 1 1/2" HEX BOLT (PL) 6
11 81568 5/16" HEX NUT (PL) 6
12 81578 3/8" X 1 3/4" HEX BOLT (PL) 2
13 81620 1/2" X 1 1/4" HEX BOLT PL 6
14 84039 WASHER - 3/8" SAE FLAT (PL) 4
15 84048 1/2" SAE FLAT WASHER (PL) 9
16 84072 3/8" X 3/4" HEX BOLT (PL) 2
17 84335 5/8 X 2 1/2" HEX BOLT (PL) 1
18 84498 1/4" LOCK NUT (PL) 12
19 86170 3/8" X 1" HEX BOLT GR.5 (PL) 12
20 86171 3/8" X 1 1/4" HEX BOLT (PL) 2
21 87553 1/2" X 1 3/4" HEX BOLT (PL) 2
22 930980 PINION ROLLER SPACER 1
23 930982 COLLECTOR STOP 2
24 930985L PLATE - DOOR 1
25 930986 PINION RIGHT SIDE SEAL 1
26 930989 TRACK ROLLER 1
27 930991 WELDT - 16 TOOTH SPROCKET AND HUB 1
28 930994 BRKT - GEARBOX Z BRACKET 1
29 930997 WELDT - COLLECTOR COVER 1
30 931005 PLATE - WEAR STRIP 2
31 931009 PLATE - CB LEFT SIDE SEAL 1
32 931010 4168 GEARBOX-UPPER 68 DEG 1
33 931392 PLATE - COLLECTOR COVER WEAR STRIP 4
34 931399 WELDT - COLLECTOR 1
35 931427 TRACK ROLLER BEARING 2
36 931592 WELDT - SPLINE TUBE 1
37 931593 WELDT - PINION SPROCKET 1
38 931594 PINION ROLLER 1
39 931596 DOUBLE 60 CHAIN 1
40 931597 BRAKE MOTOR 1
41 931616 3/8" X 2-1/4" SOCKET CAP SCREW GR.5 (PL) 2
