Parts Identiļ¬cation - Teleswing
59
ITEM PART NUMBER DESCRIPTION QTY.
42 931640 1/4" X 1" FLAT SOCKET CAP SCREW GR.5 (PL) 12
43 931662 5/16" X 5/16" X 1" KEY 1
44 932110 808 WOODRUFF KEY 1
45 932116 #10 FLAT WASHER PL 14
46 932117 10-24 X 3/4 PAN HEAD MACH. SCREW GR.5 (PL) 14
47 932118 #10-24 LOCK NUT (PL) 14
48 933133 WELDT - RIGHT SWING RING MOUNT BRACE 1
49 933134 WELDT - LEFT SWING RING MOUNT BRACE 1
50 933165 5/16 - 18 UNC RIBBED RIVET NUT 6
51 934237 PLATE - CB RIGHT SIDE SEAL 1
52 934238 PINION LEFT SIDE SEAL 1
53 934701 ASSY - ROLLER FLANGE 1
54 934732 1/4" X 1 1/2" SOCKET CAP SCREW FULL THR GR.5 1
55 960789 WOODEN BEARING ( 1 3/8") 1
56 968601 5/16" WING NUT 5
