Parts Identiļ¬cation - Teleswing
61
ITEM PART NUMBER DESCRIPTION QTY.
1 811796 1/2" X 2 1/2" HEX BOLT GR5 (PL) 1
2 812026 5/16" X 1" HEX BOLT (PL) 10
3 812362 5/16" LOCK NUT (PL) 10
4 812363 3/8" LOCK NUT (PL) 8
5 812364 1/2" LOCK NUT (PL) 3
6 812482 5/8" LOCK NUT (PL) 1
7 812639 WASHER 0.625 SAE FLAT BS PL 2
8 81544 1/4" HEX NUT (PL) 1
9 81546 5/16" FLAT WASHER (PL) 20
10 81578 3/8" X 1 3/4" HEX BOLT (PL) 2
11 81619 1/2" X 1" HEX BOLT (PL) 6
12 84039 WASHER - 3/8" SAE FLAT (PL) 2
13 84048 1/2" SAE FLAT WASHER (PL) 3
14 84072 3/8" X 3/4" HEX BOLT (PL) 2
15 84335 5/8 X 2 1/2" HEX BOLT (PL) 1
16 86170 3/8" X 1" HEX BOLT GR.5 (PL) 2
17 87553 1/2" X 1 3/4" HEX BOLT (PL) 2
18 930980 PINION ROLLER SPACER 1
19 930982 COLLECTOR STOP 2
20 930985L PLATE - DOOR 1
21 930989 TRACK ROLLER 1
22 930991 WELDT - 16 TOOTH SPROCKET AND HUB 1
23 931005 PLATE - WEAR STRIP 2
24 931427 TRACK ROLLER BEARING 2
25 931593 WELDT - PINION SPROCKET 1
26 931594 PINION ROLLER 1
27 931596 DOUBLE 60 CHAIN 1
28 931597 BRAKE MOTOR 1
29 931616 3/8" X 2-1/4" SOCKET CAP SCREW GR.5 (PL) 2
30 931662 5/16" X 5/16" X 1" KEY 1
31 932110 808 WOODRUFF KEY 1
32 932116 #10 FLAT WASHER PL 14
33 932117 10-24 X 3/4 PAN HEAD MACH. SCREW GR.5 (PL) 14
34 932118 #10-24 LOCK NUT (PL) 14
35 932914 BRKT - GEARBOX Z MOUNT A 1
36 932915 BRKT - GEARBOX Z MOUNT B 1
37 932924 UPPER COLLECTOR END SEAL 1
38 932925 PINION END SEAL LEFT 1
39 932926 PINION END SEAL RIGHT 1
40 932927 4168 GEARBOX-UPPER 68 DEG 1
41 932932 ASSY - SPLINE TUBE 1
