Parts Identiļ¬cation - Teleswing
75
ITEM PART NUMBER DESCRIPTION QTY.
1 812114 3/4" X 5 1/2" HEX BOLT (PL) 2
2 812362 5/16" LOCK NUT (PL) 3
3 812364 1/2" LOCK NUT (PL) 4
4 812365 3/4" LOCK NUT (PL) 2
5 812591 BOLT CARR 0.313 NC X 1.50 GR5PL 2
6 812624 1/4" FLAT WASHER PL 30
7 81527 1/4" X 1" HEX BOLT (PL) 22
8 81546 5/16" FLAT WASHER (PL) 1
9 81598 7/16" X 1 1/4" HEX BOLT (PL) 8
10 81620 1/2" X 1 1/4" HEX BOLT PL 4
11 84041 7/16" SAE FLAT WASHER (PL) 20
12 84048 1/2" SAE FLAT WASHER (PL) 8
13 84498 1/4" LOCK NUT (PL) 22
14 86273 7/16" LOCK NUT (PL) 16
15 900930 1/4" X 1/4" X 1-1/2" KEY 1
16 930969L PLATE - UPPER WASHER CB 1
17 931508 SPLINE SHAFT END BEARING HOUSING 1
18 931783 WELDT - HOPPER 1
19 931877L PLATE - SKIRT RETAINER 2
20 931891 ASSY - 21 TOOTH IDLER 1
21 932011 WELDT - RIGHT FEED SCREW 1
22 932012 WELDT - LEFT FEED SCREW 1
23 932015 FEED SCREW BUSHING 2
24 932017 WELDT - FEED SCREW BUSHING HANGER 2
25 932018 ASSY - TRANSFER SCREW 1
26 932022 GUARD - HOPPER MESH 1
27 932023 BRKT - TRANSITION INSPECTION COVER 1
28 932024 BRKT - INNER CARRIAGE PLATE 2
29 932028 HOPPER SKIRT 1
30 932033 WELDT - HOPPER JACK SHAFT 1
31 932040 7/16" X 1 1/2" CARRIAGE BOLT GR5 (YZ PL) 8
32 932041 21 TOOTH #60 SPROCKET AND HUB 1
33 932042 DOUBLE 21 TOOTH #60 DRIVE 1
34 932043 WELDT - RH FEED SCREW DRIVE AND IDLER 1
35 932052 HAND TRUCK TIRE & WHEEL ASSEMBLY ZIGZAG 2
36 932057 WELDT - HOPPER CHAIN GUARD 1
37 932061 3/8" X 1" UNF HEX BOLT GR.8 (YZ PL) 1
38 932068 HOPPER LEFT FLIGHT DRIVE CHAIN 1
39 932069 HOPPER RIGHT FLIGHT DRIVE CHAIN 1
40 932207 EXTERNAL RETAINING RING 1
41 932208 EXTERNAL RETAINING RING 1
