Farm King 13'' - Page 81

Parts Identification - Teleswing
79
ITEM PART NUMBER DESCRIPTION QTY.
1 812114 3/4" X 5 1/2" HEX BOLT (PL) 2
2 812362 5/16" LOCK NUT (PL) 2
3 812364 1/2" LOCK NUT (PL) 14
4 812365 3/4" LOCK NUT (PL) 2
5 812591 BOLT CARR 0.313 NC X 1.50 GR5PL 2
6 812624 1/4" FLAT WASHER PL 28
7 813059 1/2 X 2" CARRIAGE BOLT GR.5 (PL) 8
8 81525 1/4" X 3/4" HEX BOLT (PL) 12
9 81527 1/4" X 1" HEX BOLT (PL) 16
10 81598 7/16" X 1 1/4" HEX BOLT (PL) 8
11 84041 7/16" SAE FLAT WASHER (PL) 8
12 84048 1/2" SAE FLAT WASHER (PL) 8
13 84277 1/2" X 1 1/2" HEX BOLT (PL) 6
14 84498 1/4" LOCK NUT (PL) 28
15 86273 7/16" LOCK NUT (PL) 8
16 900930 1/4" X 1/4" X 1-1/2" KEY 2
17 905769 KEY - INT AUG TO HOPPER 3/8" X 3/8" X 1 1/2" 1
18 930969L PLATE - UPPER WASHER CB 1
19 931508 SPLINE SHAFT END BEARING HOUSING 1
20 931891 ASSY - 21 TOOTH IDLER 1
21 932042 DOUBLE 21 TOOTH #60 DRIVE 1
22 932052 HAND TRUCK TIRE & WHEEL ASSEMBLY ZIGZAG 2
23 932061 3/8" X 1" UNF HEX BOLT GR.8 (YZ PL) 1
24 932208 EXTERNAL RETAINING RING 1
25 932623 WELDT - HOPPER CHAIN GUARD 1
26 932627 FLANGE & BEARING W/ LOCK COLLAR 2
27 932628 21 TOOTH #60 SPROCKET AND HUB 1
28 932629 ASSY - TRANSFER SCREW 1
29 932634 BRONZE BUSHING 2
30 932646 WELDT - LEFT BUSHING HOLDER 1
31 932647 WELDT - RIGHT BUSHING HOLDER 1
32 932648 BRKT - TRANSITION INSPECTION COVER 1
33 932649 WELDT - RIGHT FEED SCREW 1
34 932650 WELDT - LEFT FEED SCREW 1
35 932657 WELDT - JACK SHAFT FEED SCREW 1
36 932660 HOPPER SKIRT 1
37 932661 HOPPER RIGHT FLIGHT DRIVE CHAIN 1
38 932662 HOPPER LEFT FLIGHT DRIVE CHAIN 1
39 932664 GUARD - HOPPER MESH 1
40 932665 WELDT - RH FEED SCREW DRIVE AND IDLER 1
