ENGLISH
17
Fig. 17: Closing hook
Once the adjustment has been made, tighten the lock nuts (B), Fig. 17.
5.3 USE OF THE CONVEYOR
1. Pour on the conveyor a quantity of capsules higher than the capacity of the conveyor itself.
Shield the free side with one hand, shake and slightly incline the conveyor with a wave motion,
to allow the capsules to place themselves in the housings. Remove the excess capsules by sliding
them from the back side where there is a gap which allows to eliminate the excess capsules, Fig.
18;
Fig. 18: Loading empty capsules inside the conveyor
