4. After making sure that all the capsules are seated in their respective cells, remove the conveyor
by pulling it upwards.
Repeat the same operations, positioning the conveyor on the other two pairs of central holes (2) and (3).
5.4 USE OF THE CAPSULE FILLING
1. Once the conveyor loading procedure has been completed, align the capsules by lowering the
closing lid, Fig. 23;
With the capsules aligned, the lid can be raised.
Fig. 23: Capsule caps lined up
2. Lock the capsule bodies by pressing the lever (G), Fig. 24;
