ENGLISH
20
Fig. 24: Capsule body block
3. Open the caps by pressing the lever (H) on the right side of the machine, Fig. 25;
Return the lever (H) to the starting position.
This operation allows to separate the body of the capsules from the heads which remain trapped
on the base plate.
Fig. 25: Extraction of body capsules
4. Remove the base plate (U) by pulling it upwards, Fig. 25;
