ENGLISH
23
8. Act on the handwheel (T) to compress the powders in the body of the capsules. When the
operation is finished, bring the handwheel to the initial position, Fig. 32.
Fig. 32: Compression handwheel
9. Unhook the hook (S);
10. Raise the pusher plate (R);
11. Complete the filling of the capsules with the spatula;
12. Remove the dosage frame (L);
13. Reinsert the base plate (U) containing the capsules heads.
5.5 CAPSULA CLOSING
1. Lower the closing cover (A), Fig. 14, locking it with the hook (D), Fig. 17;
2. Push the lever (H) so as to close the capsules, Fig. 18;
3. Raise the closing cover;
4. Lift the base plate, extract it upwards; (The capsules contained in it, now closed, will remain
retained);
5. Extract the capsules by turning the top plate upside down in a collection container.
5.6 RIGHT AND WRONG USE
The equipment must be used in full compliance with the instructions of this Handbook; any measurement
of the machine might damage the system or put in danger persons or things.
FARMALABOR S.R.L. declines any responsibility resulting from any wrong use of the
equipment.
