ENGLISH
22
To guarantee a homogeneous distribution of the powders, even in the case of poorly powders,
the vibrating unit can be activated by means of the switch (P) and adjusting the intensity of the
vibration with the potentiometer, Fig. 29;
Fig. 29: Activating vibrating unit
7. Lower the pestle plate (R) and lock it with the hook (S), Fig. 30 and Fig. 31;
Fig. 30: Pestle plate
Fig. 31: Lock hook
P
Q
R
S
