SECTION 10 -- ENGINE -- CHAPTER 1

Fuel System (continued)

All--speed governor , incorporated in pump:

BOSCH ............................................... centrifugal counterweights

Automatic advance regulator, incorporated in pump:

BOSCH ............................................... hydraulic

For further fuel system technical data:

Fixed advance (pump setting for start of delivery before TDC)

-- Pressure setting -- Injection order, and other information re-

gardingtheBOSCHpump ...............................

refer to the data for the relevant

engine type in the table on page 4

FUEL SYSTEM DATA

Turbo Charger:

-- For versions F4CE9487M*J:

--typeHOLSETHX25W ..............................

TB11H/A085BXL

-- For versions F4CE9487N*J:

--typeHOLSETHX25W ..............................

TB11K/A11CXL

Injectionpump ......................................... rotating distributor with speed governor

and advance regulator incorporated

BOSCH pump:

-- Farmall 90 model -- type F4CE9487M*J ................ VE 4/12 F1250 L2043 (S/N 504218826)

-- Farmall 95 model -- type F4CE9487N*J ................ VE 4/12 F1250 L2023 (S/N 504218827)

Directionofrotation ..................................... counter-clockwise

Injectionorder.......................................... 1--3--4--2 (For all models)

Farmall 90 Farmall 95

BOSCH--type injectors:

-- F4CE9487M*J ........................ 504254390

DSLA 145 P 1441

-- F4CE9487N*J ........................

504254390

DSLA 145 P 1441

Numberofnozzleholes ...................

Nozzle hole diameter mm (in)

-- F4CE9487M*J ........................

0.192 (0.0076)

-- F4CE9487N*J ........................

0.192 (0.0076)

Calibrationpressurebar(psi)...............

260 to 272 (3771 to 3945)
