Farmall 90 - Fitting the Auxiliary Member Drive Belt

80
SECTION 10 -- ENGINE -- CHAPTER 1
6. Fit the fan pulley (2) on the support (1) with the
screws (3), tightening them to torque.
MIF1153A
164
7. Fit the tightener (1), tightening the bolts (2) and
the tightener nut as directed on page 112.
MIF1154A
165
Fitting the Auxiliary Member Drive Belt
(Disassembly operation 24.)
1. Fit the Poly--V belt (3) on the pulleys of the crank-
shaft, tightener (5) of the coolant pump (4), alter-
nator (1) and fan (2).
NOTE: Tension the belt correctly as indicated in op-
eration 10 414 10.
MIF1155A
166
