76
SECTION 10 -- ENGINE -- CHAPTER 1
4. Spline the flywheel (1) onto the crankshaft, tight-
ening the screws (2) by hand.
5. Lock the flywheel appropriately before tightening
the relevant screws to torque.
MIF1115A
152
6. Tighten the bolts (1) securing the engine flywheel
(2) in two stages as described on page 13:
- 1
st
phase, tightening with torque
wrench to a torque of 30 ± 5Nm;
- 2
nd
phase, tightening to an angle of 60°
± 5°.
NOTE: Tightening to an angle is done with tool
380000304.
MIF1146A
153
Fitting the Oil Pump
(Disassembly operation 35.)
1. Insert the seal.
2. Fit the oil pump (1).
3. Insert the tightening screws (2) and tighten them
to the torque prescribed on page 12.
MIF1149A
154
