Farmall 90 - Fitting the Fan-Alternator Pulley

SECTION 10 -- ENGINE -- CHAPTER 1
79
Fitting the Fan--alternator Pulley
(Disassembly operation 25.)
1. Fit the coolant temperature sensor (1) screwing
it down with a torque wrench.
2. Fit the fan pulley support (2) with the screws (3),
tightening them to the torque given on page 12.
MIF1151A
161
3. Fit on the crankcase: a new gasket (1), the cooler
(2), a new gasket (3) and the oil filter mounting
(5).
4. Insert the screws (4) and tighten them to the
torque prescribed on page 12.
MIF1152A
162
5. Refit the bracket (1) to secure the alternator (2)
to the crankcase. Tighten the alternator fixing
screws (3) to the torque specified on page 12.
MIF1006A
163
