SECTION 10 -- ENGINE -- CHAPTER 1
-- Check the clearance between the main journals
of the crankshaft and their respective bearings,
proceeding as follows:
-- Make sure that all parts are perfectly clean
and remove all traces of oil.
-- Position a length of calibrated wire (3) on the
crankshaft journals (4), parallel to the crank-
shaft centerline.
-- Fit the caps (1) complete with half bearings
(2) on the relevant supports.
MIF0964A
104
-- Insert the pre--lubricated screws (1) and tighten
them in three successive stages.
1
st
and 2
nd
phase with a torque wrench to the
torque given on page 13.
MIF0965A
105
-- 3
rd
phase with tool 380000304 (1) positioned as
in the figure, further tighten the screws (2) with an
angle of 90°±5°.
MIF0966A
106
