7.E REPLACEMENT OF FLUORESCENT LAMPS (by user).
[See chapter 13 – diagram for maintenance operations].
1. Switch the cabinet off and disconnect it from the power supply.
2. Remove the prefilter/s [10].
3. Unscrew the nuts [16] and remove the lampholder [15].
4. Replace the lamp [17] and the starter.
5. For reassembly reverse the above instructions.
6. Re-connect the cabinet .
7.F REPLACEMENT OF U.V. GERMICIDAL LAMP (optional - by user).
[See chapter 13 – diagram for maintenance operations].
1. Switch the cabinet off and disconnect UV electric connection.
2. Replace the UV lamp [18] from the inside of the work chamber, taking care not to touch the UV tube with the
hands.
3. Replace the starter
4. Reconnect UV electric connection.
IMPORTANT: During the installation of the new lamp, pay attention not to leave fingerprints on the
lamp.
