Faster FlowFAST H - Page 6

a D:GROUP company
00020EN Rev.09 – 12/2012 6
Techincal Features Table
Description Unit FlowFAST H 09 FlowFAST H 12
FlowFAST H 15
FlowFAST H 18
Overall Dimensions (L x H x P) mm 945x1195x925 1250x1195x925 1555x1195x925 1860x1195x925
Usefull dimensions (L x H x P) mm 885x734x600 1190x734x600 1495x734x600 1800x734x600
Weight Kg 95 128 175 188
Noise level dB (A) 58 58 58 58
Lighting level Lux >800 >800 >800 >800
Main voltage V 230V AC 2P+T 230V AC 2P+T 230V AC 2P+T 230V AC 2P+T
Frequency Hz 50 50 50 50
Maximum power consumption W 700 900 1400 1400
Current A 3 3.5 6 6
Electrical class 1 1 1 1
Protection level IP20 IP20 IP20 IP20
Internal outlet (maximum current for all the sockets: 4A) 2P+T 230V 4A 2P+T 230V 4A 2P+T 230V 4A 2P+T 230V 4A
Fluorescent lamps W 2x18 2x30 2x36 2x36
