2-23
Chapter 2: Motherboard information
16. Battery connector (2-pin BATTERY1)
ThisconnectorisforthelithiumCMOSbattery.
FAY-002 BATTERY connector
GND
+BAT
PIN 1
BATTERY1
17. Audio amplifier connector (4-pin AMP_CON)
Thisconnectorisforanexternalaudioamplier.
FAY-002 Audio Stere.
Output with Amp connector
AMP_CON1
ROUTP ROUTN LOUTN LOUTP
PIN1
