FCI WATERMAKERS, INC. 89Operational Instructions
PRIME SEQUENCE
During the Prime Sequence, the LPP turns on. e pump status is
then veried by the Low Pressure Transducer. It must be greater than
3 PSI and less than 50 PSI or the system will shutdown.
When the system is in Prime Sequence:
LPP – is on
HPP – is o
FWF Valve – is closed
Quality Valve – directed overboard
APC (if equipped) – is in open position
e Prime Timer counts down from its setpoint (Prime Timer Setpoint)
which is entered by the operator. Once the timer reaches zero, the timer
has expired and the system then moves to Initialize Sequence.
Timer – Indicates time le in seconds for the Prime Sequence.
Low Pressure – Shows the Low Pressure Transducer reading.
Brine Flow – Shows the Brine Flow Meter reading.
Clear – Press this button to clear the system once a shutdown has taken place.
Stop – Press this button to stop the system.
Navigation Bar – is allows the user to easily navigate between main screens.
Right Arrow – When pressed, system will proceed to the Initialize Sequence.
SYSTEM FUNCTIONALITY (continued)
