FEB-9455 User’s Manual
10
1.5 Connector Function List
Connector Function Note
AUDIO1 6W amplifier Line-out Connector
AUDIO2 Line-in, MIC-In Connector
AUXFAN1 System FAN 3-pin Connector
BT1 Power Button Connector
CF1 Compat Flash Connector
CPUFAN1 CPUFAN 4-pin Connector
COM5,COM6 Serial port Connector with Box-header
DIMM1 DDR2 240 Pin Slot
DIO1 Digital I/O with Pin-header
IDE1 HDD IDE Connector (Supply +5V)
INV1 LCD inverter Connector
IR1 IrDA Connector
MIO1 Multi IO Connector
MCR1 MSR Connector with Box-header
LAN LAN Connector with Pin-header
LPT1 Printer Connector with Pin-header
LVDS1 LVDS Connector
PCI PCI Connecting Finger
PWR1 ATX Connector with extension cable
PWR2 ATX 4 Pin Connector
SATA1, SATA2
SATA Connector
SATA_PWR1 SATA Power Connector
USB1, USB2,
USB3, USB4
USB Connector with Pin-header
