FEC FEB-9455 - Chapter 1 Product Information; 1.1 Block Diagram

FEB-9455 User’s Manual
4
Chapter 1 Product Information
This chapter introduces the product features, jumper and connector information.
1.1 Block Diagram
Intel LGA775
Intel 945G/GC
VRD10/11
CK410
VGA
LVDS_CH7308
FSB 533/800/1066MHz
DDR2 400/533/667 MHz
DMI
S/IO W83627EHG
IDE / CF
USB x8
COM1
SPI
DIOPrinterKB/MS IrDA
LAN_RTL8102E
CODEC_ALC662
Intel ICH7
USB
SATA
LPC
PCI
SPI
DDR2(240 Pin)
SATA x2
PCI-E
SDVO
PCI
IDE
S/IO F81216D
COM3/4/5/6
HDA
COM2
MIO (Multi IO Connector)
COM1, COM2, COM3, COM4, VGA, LAN, PS2 KB/MS
