USB2：USB1 Port Connector with Pin-header (2.0mm)
Pin No. Signal
1 USB Power (+5V)
2 USB DATA1-
3 USB DATA1+
4 Ground
USB3：USB2, USB3, USB4, USB5 Port Connector with Pin-header (2.0mm)
Pin No. Signal Pin No. Signal
1 USB DATA2- 2 USB DATA4-
3 USB DATA2+ 4 USB DATA4+
5 Ground 6 Ground
7 USB DATA3- 8 USB DATA5-
9 USB DATA3+ 10 USB DATA5+
USB4：USB6, USB7 Port Connector with Pin-header (2.0mm)
Pin No. Signal
1 USB DATA6-
2 USB DATA6+
3 Ground
4 USB DATA7-
5 USB DATA7+
