TST Startup WUI
FEIG ELECTRONIC GmbH Page 16 of 20 WUI_Inbetriebnahme2_GB.doc
11 Messages overview
11.1 Error messages
Improper end positions
F.000
Position too far up
• Too small a parameter value for upper emergency limit switch
• Upper limit switch range (limit switch band) too small
• Mechanical brake defective or improperly set
F.005
Position too far down
• Too small a parameter value for lower emergency limit switch
• Lower limit switch range (limit switch band) too small
• Mechanical brake defective or improperly set
Implausibilities in door movement
F.020
Run time exceeded (during
opening, closing or deadman)
• current motor run time has exceeded set maximum run time, door
may be sticking or is blocked
• If using mechanical limit switches, one may not have tripped
F.030
Lag error (position change of
the door is less than expected)
• Barrier or motor is blocked
• Too little power for lift torque
• To little speed
• Mechanical limit switch was not left or is defective
F.043
Pre-limit switch fault (light
barrier)
• The pre-limit switch for the light barrier remains activated even in
the middle end position or upper end position.
Maintenance counter exceeded
F.080
Fault: Maintenance is required
• Service counter has expired
Parameters not set
F.090
Controller not parameterized
• The basic parameters (P.205) for the TST WUI controller have not
yet been set.
Safety chain faults
F.201
Internal E-Stop „push-button“
tripped
or Watchdog (computer
monitor)
• E-Stop chain was interrupted starting at input „internal E-Stop“
without parameterizing mode having been selected
• Internal parameter or EEPROM checks defective, pressing the
STOP key provides additional information about the cause
F.211
External E-Stop 1 tripped
• E-Stop chain was interrupted starting at Input 1 (terminals 1 and 2)
F.212
External E-Stop 2 tripped
• E-Stop chain was interrupted starting at Input 2 (terminals 3 and 4)
Faults in the safety chain
F.360
Short circuit detected on edge
input
• Short circuit detected on edges with normally closed contact
F.361
Number of edge trips for
closing has reached set limit
• Parameterized, maximum number of safety edge trips during a
door cycle was exceeded
