Safety edge input
for electric safety edges with 1.2kΩ or 8.2kΩ terminal resistance
and for dynamic optical systems
Relay outputs if inductive loads are switched (e.g. further relays or brakes), they
must be equipped with corresponding noise suppresion
measures (free-wheeling diodes, varistors, RC elements)
Relays K1, K2:
⇒ 24VDC / 500 mA
⇒ 230 VAC / min. 0.1 A / max.
80 W
potential-free switching, change-
over contact
Contacts which have been
used once for power switching
can no longer switch extra-low
voltage
Relays K3, ... K14:
⇒ 24VDC / 1A
⇒ 120 VAC / 0,5A
potential-free switching, N.O.
contact
Contacts which have been
used once for power switching
can no longer switch extra-low
voltage
Drive output: 3x 400VAC, max. 2.2 kW for AC-3
Reversing contactor is prepared for operating three-phase drives
Max. length of the motor cable: 30m
electromechanical brake 230 V
AC
-control via switched motor phase and N
Operating temperature range: -10...+50°C
Storage temperature range -20...+70°C
Air humidity up to95% not condensating
Mains cable installation Y, the mains cable must only be replaced by the manufacturer or
his after-sales service or by another qualified person
Equipment mobility stationary
Protection class Protection class I
Equipment type Motor appliance, external motor is not part of the delivery from
FEIG ELECTRONIC GMBH
Vibration low vibration installation, e.g. on a brick wall
Protection class IP54 (IP65 by replacing CEE connection and sealing cable
entries)
All unused cable entries must be closed.
Weight ca. 2.8 kg
Directives Standards:
EMV-Directive: 89/336/EWG
modified by: 91/263/EWG
92/031/EWG
93/068/EWG
EN 50081-1 / 03.93: interference emissions, residential
area
EN 50081-2 / 03.94: interference emissions, industrial area
EN 61000-6-2 / 2001: interference resistance, industrial area
Low voltage directive:
73/023/EWG
modified by: 93/068/EWG
EN 60335-1 / 2003: Safety of electrical appliances for
domestic use and similar purposes /
Part 1
Prototype tested according to: EN12453 / 2001: Usage safety of power-operated gates
– requirements
EN12445 / 2001: Usage safety of power-operated gates
– test methods
Applied national technical
specifications concerning the
directives mentioned above
EN12978 / 2003: Gates – safety equipment –
requirements and test methods
