BOP 6 (A); BOP 10 (A); BOP 10-2 (A); BOP 13-2 (A)
7. Fitting
C-SC_CSSM
Version 1.0
2017-10-12
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 37 of 65
Fitting the carbon brush [on both sides]
1. Insert the carbon brush (1) in the correct position and connect it.
2. Place the spring (2) on the carbon brush.
Tools:
- Assembly aid
1
2
