Fein BOP 6 - Page 51

BOP 6 (A); BOP 10 (A); BOP 10-2 (A); BOP 13-2 (A)
7. Fitting
C-SC_CSSM
Version 1.0
2017-10-12
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 51 of 65
Fitting the gearbox housing [applies to: BOP 10 (A)]
1. Position the disc (1).
2. Press on the grooved ball bearing (2).
3. Fill the gearbox housing (3) with 25 g of grease.
Tools:
- Arbor press
- Sleeve
6 mm inner diameter
20 mm outer diameter
- Grease
1
2
3
