FeiYu Tech SCORP Mini - Control Ports

- 28 -
Start shooting
1 2
+
Smoothness
Preview
Horiz 0° Vert 0°
Start shooting
1
+
Smoothness
Preview
Horiz 0° Vert 0°
The shooting progress will show up on the screen, if need to stop it midway, tap
"Stop shooting" to stop it.
After the shooting complete, tap "Con󽗉rm and return" to exit.
8.4 Control ports
There is a camera control port and extension port on the 󽗉xed plate, to control
camera and other extension devices, such as focus motor, etc.
UART
1
2
①
Camera control port
②
Extension port (connect focus
motor and etc.)
