FELIXprinters Assembly Manual for the FELIX One
Page 19
77
(1x) L-Bracket
75 76
(3x) Bolt M3 x 16
(1x) L-Bracket Assembly
(1x) Motor
(1x) Square Nut M4
(1x) Extruder Arm Assembly
(1x) Spring Assembly
74
(1x) Bolt M4 x 40
Bolt is used to keep square nut
in place during assembly.
!! Repeat this Step !!
Tools:
3
Tools:
2,5
Motor E1
Motor E1 Motor E1
