FELIXprinters Assembly Manual for the FELIX One
Page 20
95
Label end of the hot-endcable: 0
96
Make sure the sticker from the fan is at the back.
The fan blows on the side of the sticker
Mount the bolt loosely.
Label end of the wire: 2
Align the print head on the carrier
Tools:
97
2,5
99
100
98
(2x M4) Place nuts for ease of
assembly.
Tools:
2,5
!
Tighten the bolt
!
