FELIXprinters Assembly Manual for the FELIX One
Page 31
125
123 124
(1x) Display Assembly
(1x) Control Board
122
(4x) Square Nut M4 Tools:
!! Plug the connector into the
matching socket description !!
end X = Endswitch X (Opto sensor)
end Y = Endswitch Y (Opto sensor)
Z sensor cable has no label.
