Fellowes ESI Evolve - Page 11

Desk clamp assembly For worksurface 0.66”- 2.2”
Step 2B
Replace the clamping component
in the lower position and secure
with the 4mmAllenkey.
Step 2A
Remove the clamping
component from the
upper position with the
4mmAllenkey.
Optional adjustment
for thicker worksurfaces
1.38”-2.99”
Step 1
Adhere the adhesive pad
underneath the base to protect
the worksurface.
Step 2 (optional)
Adjust clamp positioning
to accommodate a thicker
worksurface.
Step 3
Slide onto worksurface
to desired position.
Step 4
Twist to tighten the desk clamp
on the worksurface.
11
